Another Basic Repair Course Completed

By on March 31, 2011

This time there were 7 participants and most of them have very little knowledge in electronics repair. One came from Sarawak, one from Kelantan, one from Penang and another one from Johor.  This proved that when a person have a passion for certain things they do not mind coming from far as long as they could learn something new in their life.  Some brought along their machine board (mostly industrial board) for me to check and i have advised  them on how to troubleshoot it. Here are the photos taken during the 3 day basic electronic repair course that was conducted in my office:

 basic electronics course

 basic electronics course

basic electronics course

basic electronics course

Likes(0)Dislikes(0)

10 Comments

  1. Ralph E. Macleod

    March 31, 2011 at 7:01 am

    Hello again Jestine,
    Can you tell me if the CCFL LAMP TESTER by SERVITEC you show on your Utube video is available for retail sale?
    Without a CCFL tester It is difficult to diagnose if any tubes are defective.
    Ralph

    Likes(0)Dislikes(0)
  2. admin

    April 1, 2011 at 8:20 am

    HI Ralph,

    Sorry i have no info on that tester but you can visit this link below for another type of ccfl tester:

    http://cgi.ebay.com/Backlight-Tester-CCFL-Lamp-Tester-Adapter-New-/290543366615

    Jestine

    Likes(0)Dislikes(0)
  3. Torregosa Rene L.

    April 2, 2011 at 2:46 am

    hello jestine, can you teach me what is the problem of 21 inc tv .tcl brand.the symptoms are when tv si a minute ago in operation ti is automaticaly shutoff and then a second back to turn on.

    Likes(0)Dislikes(0)
  4. admin

    April 2, 2011 at 4:54 am

    HI Torregosa,
    Try check for dry joints in the power, high voltage and crt board side. Maker sure there is no bad e-caps in the power side.

    Jestine

    Likes(0)Dislikes(0)
  5. Wim

    April 2, 2011 at 6:35 am

    Hi guy's
    I just find your site here and see that you all sometimes look for schematics or electronics info.

    Follow our twitter page @techniforum or come to our website and join the community with other technicians.

    We also have many trainingmanuals.

    Best Regards Wim72

    Likes(0)Dislikes(0)
  6. admin

    April 2, 2011 at 6:54 pm

    Hi Wim,

    You've got a good repair forum-thanks for the link!

    Jestine

    Likes(0)Dislikes(0)
  7. tu foon

    July 23, 2011 at 6:35 am

    good day jestine,
    i'm working on a panasonic pf-61lcx65 lcd that would not turn on.firstly ,when switch off you,d have to unplug then to switch on.i changed some caps on the p.s. board and still wouldn,t power up.would appreciate any advice.

    Likes(0)Dislikes(0)
  8. admin

    July 23, 2011 at 7:17 am

    HI Tufoon,

    Ok, the moment you power on did you get any dc output voltages from the power supply? Or there are output voltages and then it shutdown? What is the color of the lcd tv power LED?

    Jestine

    Likes(0)Dislikes(0)
  9. Haidar

    September 8, 2011 at 7:57 pm

    Hi,prof Justine
    would you please help me,
    my LCD monitor (Model:Sensy)shut down every amount 2 second,I have checked if there's a short circuit or bulged capacitors,nothing
    in end a have changed all capacitors with new one not the same value.
    Old capacitors (1000uf/16V and 470uf/25v)
    New capacitors (1500uf/25V).
    but unfortunately the problem persist
    tell me please if there's other component can cause this shut down
    best regards

    Likes(0)Dislikes(0)
  10. admin

    September 9, 2011 at 2:45 am

    HI Haidar,

    If everything check to be good then suspect one of the backlight have problem. By the way, I'm not a prof just a normal repairer.

    Jestine

    Likes(0)Dislikes(0)
