Kingston USB Repaired

By on July 24, 2015
usb repair















This USB Flash Memory brand KINGSTON model DT101 G2 with a capacity of 8GB was brought to me and the complaint was it was not working.

kingston usb repair

I connected it into the USB port of the PC and it was not recognized by Windows Operating System.

Therefore the duty began; the device was disarmed step by step.

usb repair2

When the PCB could be seen, look what was seen in the photo below.

usb repair3

The four pins were separated from the PCB. Therefore they had to be re-soldered, but first I had to de-solder the metallic case from the circuit to re-build the tracks.

usb repairing

Thanks God the two connectors of the center (Data+ and Data-) had not lost the connection with the tracks. One of the ends (+5v) was only de-soldered, but the track of the circuit was intact. The other end (Gnd) was broken, in other words, the track attached to this point was broken (open- circuit).

The metallic case was re-soldered into the circuit again. So the two contacts of the center were intact in this repair, nothing was done with them. The end of +5v was re-solder with its own track, and the end of Gnd was attached with the circuit by scratching the other good side of the track and joining both tracks by means of tin.

usb repairing

At this time the device was armed again and connected into the PC. Look yourself the results.

usb repair6

Mission Accomplished
